Micronization mill with dynamic selector type "SV MICRO," designed for fine and very fine micronization of minerals, chemicals and plants. The dynamic particle size selection system allows precise adjustment in the 15-100 micron range. The air sucked through the mill can be heated to dry wet products, or cooled to treat heat-sensitive products.

Input power supply: 0 to 10 mm
Fineness range: 15 ÷ 100 microns
Scope: 300 to 3000 t/hour

Mills suitable for materials of medium hardness and abrasiveness, ideal for intermediate grinding with high production of fine powders. Perfect for combined drying and grinding processes. Processes calcium carbonate, dolomite, coke, lime, gypsum, clays and brick waste. Also available in a version with integrated drying.

Input power supply: less than 100 mm
Fineness range:0 ÷ 3 mm
Scope: up to 70 t/hour

Cimma rotary dryers, customized for each material, offer countercurrent or equicurrent drying modes and direct or indirect heating. Built with single or double cylinders, they ensure thermal efficiency and easy maintenance. Comprehensive accessories support feeding, discharging and safety. Reliable and flexible solutions for every industrial need.

Scope: 5 to 50 t/hour
Maximum humidity: 5 to 30%
Thermal capacity: from 500,000 KCal/hour to 5,000,000 KCal/hour

The P version impact mill with rigid hammers is designed for the production of fine sands and powders with constant grain size. Suitable for grinding limestone, marble, clay, gypsum and other friable materials. Ideal for premixes, ceramics, special plasters. Excellent reliability, low consumption and long operating life. Also available in a version with integrated drying.

Input power supply: up to 30 mm
Fineness range: 0 ÷ 3 mm
Scope: up to 12 t/hour

The IMPACT mill crushes hard and wet materials such as clay, dolomite, and industrial waste. Without a screen, it avoids clogging and reduces wear and tear. Adjustable and sturdy, it is ideal for primary crushing in construction, ceramics and foundry.

Input power supply: 250x250mm
Fineness range: less than 30 mm
Scope: up to 120 t/hour

The SM Crusher is designed for crushing hard, wet or dry clays and agglomerated materials. Equipped with two harpooned cylinders at different speeds, it effectively reduces clods and agglomerates by preparing them for grinding. Sturdy structure, anti-wear system and easy maintenance.

Input power supply: 250x250mm
Fineness range: less than 30 mm
Scope: up to 120 t/hour

The "D"-series impact mill with oscillating hammers is ideal for crushing bulky and medium-hard materials. Used to produce sand, grit and recycled materials. Used in the ceramic, brick and gypsum processing sectors. Strong structure, easy maintenance, durable even with slightly abrasive materials. Also available in a version with integrated drying.

Input power supply: up to 150 mm
Fineness range: less than 10 mm
Scope: up to 15 t/hour

The BL series hammer mill is designed for grinding grain, wood chips, locust beans and feed. Sturdy construction, adjustable feed and hammers on 4 sides. Suitable for nonabrasive products, can include magnetic plate and collect by gravity or pneumatic conveying.

Input power supply: up to 100 mm
Fineness range: less than 5 mm
Scope: up to 5 t/hour

The double-rotor hammer mill type "ROTODUE 4/C" with dynamic air selector is ideal for grinding and drying friable materials such as coke, gypsum, calcium carbonate and talc. It produces ventilated powders up to 300 microns. Sturdy, adjustable and compact, it saves energy and reduces plant footprint.

Input power supply: 0 to 20 mm
Fineness range: 0 ÷ 100 mm
Scope: up to 10 t/hour
